Configuring VLANs (Virtual LANs) with the 802.1Q standard on a FortiGate firewall involves several key steps to ensure proper network segmentation and communication. Let's dive deep into how you can set this up, making sure your network is both secure and efficient.

Understanding VLANs and 802.1Q

Before we get our hands dirty with the configuration, it's crucial to understand what VLANs and the 802.1Q standard are all about. VLANs are basically a way to create multiple logical networks on a single physical network. This is super useful because it allows you to segment your network without having to physically separate devices. Think of it like having multiple separate networks within your existing network infrastructure. Each VLAN operates as its own broadcast domain, enhancing security and reducing unnecessary network traffic. 802.1Q, on the other hand, is the IEEE standard that supports VLANs on an Ethernet network. It does this by adding a tag to the Ethernet frame, which includes VLAN membership information. This tag tells network devices which VLAN the frame belongs to, allowing them to forward the frame only to the appropriate ports.

Why is this important? Well, imagine you have different departments in your company – like Sales, Marketing, and Engineering. You probably don't want everyone in Sales having access to Engineering's sensitive data, right? By using VLANs, you can isolate these departments from each other, improving security and preventing unauthorized access. Plus, VLANs can also help improve network performance by reducing the size of broadcast domains, meaning less unnecessary traffic floating around. So, in a nutshell, VLANs and 802.1Q are essential tools for creating a well-organized, secure, and efficient network.

Prerequisites

Before you start configuring VLANs on your FortiGate, there are a few things you need to have in place. First, make sure you have a FortiGate firewall that is properly set up and running. You should have administrative access to the FortiGate's web interface or CLI (Command Line Interface). This is essential because you'll need to make changes to the FortiGate's configuration. Next, identify the network segments you want to isolate using VLANs. For example, you might want to create separate VLANs for different departments like Sales, Marketing, and IT, or for different types of devices like servers, workstations, and IoT devices. Plan your VLAN numbering scheme. VLAN IDs are numbers between 1 and 4094, so you'll need to decide which IDs to assign to each VLAN. It's a good idea to use a consistent and logical numbering scheme to make it easier to manage your VLANs in the future. For instance, you could assign VLAN IDs in the 100s to your Sales department, 200s to Marketing, and so on. Finally, ensure you have a clear understanding of your network topology, including which ports on your FortiGate will be used for VLAN trunking and which ports will be used for access ports. Trunk ports carry traffic for multiple VLANs, while access ports carry traffic for only one VLAN. Having this information handy will make the configuration process much smoother.

Step-by-Step Configuration Guide

Alright, let's get into the nitty-gritty of configuring VLANs on your FortiGate. Here's a step-by-step guide to walk you through the process. First, log in to your FortiGate's web interface using your administrator credentials. Once you're logged in, navigate to Network > Interfaces. This is where you'll create and configure your VLAN interfaces. Click on Create New > Interface to start creating a new VLAN interface. In the Interface Name field, enter a descriptive name for your VLAN, such as VLAN_Sales or VLAN_Marketing. This will help you easily identify the VLAN later on. In the Type field, select VLAN. This tells the FortiGate that you're creating a virtual LAN interface. In the Interface field, select the physical interface that will carry the VLAN traffic. This is usually an Ethernet port, such as port1 or port2. In the VLAN ID field, enter the VLAN ID you've chosen for this VLAN. Remember, VLAN IDs are numbers between 1 and 4094. Make sure the VLAN ID matches the one you've planned for this network segment. In the Addressing Mode field, select Manual if you want to assign a static IP address to the VLAN interface, or DHCP if you want the interface to obtain an IP address automatically from a DHCP server. Enter the IP address and netmask for the VLAN interface if you've chosen Manual addressing mode. For example, you might assign the IP address 192.168.10.1/24 to the VLAN_Sales interface. Configure any other relevant settings, such as security mode, administrative access, and traffic shaping. These settings will depend on your specific network requirements. Click OK to save the VLAN interface. Repeat these steps for each VLAN you want to create. Once you've created all your VLAN interfaces, you'll need to configure your FortiGate's firewall policies to allow traffic to flow between the VLANs. Navigate to Policy & Objects > Firewall Policy and create new policies to allow or deny traffic based on your security requirements. Remember to specify the source and destination VLAN interfaces in your firewall policies to ensure traffic is routed correctly.

Configuring 802.1Q VLANs via CLI

For those of you who prefer the command line, here’s how to configure 802.1Q VLANs on your FortiGate using the CLI. First, access the FortiGate CLI using SSH or the console port. Once you're logged in, enter the following commands to create a VLAN interface:

config system interface
    edit <vlan_interface_name>
        set vdom root
        set interface <physical_interface>
        set vlanid <vlan_id>
        set ip <ip_address> <netmask>
        set allowaccess ping https ssh http
        set type vlan
    next
end

Replace <vlan_interface_name> with a descriptive name for your VLAN interface, such as VLAN_Sales. Replace <physical_interface> with the name of the physical interface that will carry the VLAN traffic, such as port1. Replace <vlan_id> with the VLAN ID you've chosen for this VLAN. Replace <ip_address> and <netmask> with the IP address and netmask you want to assign to the VLAN interface. The set allowaccess command specifies which management protocols are allowed on the interface. In this example, we're allowing ping, HTTPS, SSH, and HTTP access. Repeat these commands for each VLAN you want to create. Once you've created all your VLAN interfaces, you'll need to configure your FortiGate's firewall policies to allow traffic to flow between the VLANs. Enter the following commands to create a firewall policy:

config firewall policy
    edit <policy_id>
        set srcintf <source_vlan_interface>
        set dstintf <destination_vlan_interface>
        set srcaddr all
        set dstaddr all
        set action accept
        set schedule always
        set service ALL
        set logtraffic all
    next
end

Replace <policy_id> with a unique ID for the firewall policy. Replace <source_vlan_interface> with the name of the source VLAN interface. Replace <destination_vlan_interface> with the name of the destination VLAN interface. The set srcaddr all and set dstaddr all commands specify that the policy applies to all source and destination IP addresses. The set action accept command specifies that traffic matching the policy should be accepted. The set schedule always command specifies that the policy is always active. The set service ALL command specifies that the policy applies to all services. The set logtraffic all command specifies that all traffic matching the policy should be logged. Repeat these commands for each firewall policy you want to create. Remember to adjust the source and destination interfaces, addresses, and services to match your specific security requirements.

Verification and Troubleshooting

After configuring your VLANs, it's important to verify that everything is working as expected. Here are a few things you can do to check your configuration. First, use the ping command to test connectivity between devices on different VLANs. For example, if you have a device on the VLAN_Sales network and a device on the VLAN_Marketing network, try pinging the device on the VLAN_Marketing network from the device on the VLAN_Sales network. If the ping is successful, it means that traffic is flowing correctly between the VLANs. If the ping fails, it could indicate a problem with your VLAN configuration, firewall policies, or routing settings. Next, use the traceroute command to trace the path that traffic takes between devices on different VLANs. This can help you identify any bottlenecks or routing issues in your network. For example, you can use traceroute to see if traffic is being routed through the correct interfaces and VLANs. Check your FortiGate's logs for any errors or warnings related to VLANs. The logs can provide valuable information about what's going on in your network and help you troubleshoot any issues. Look for messages related to VLAN interface creation, VLAN ID mismatches, or firewall policy violations. Use the get system interface <interface_name> command to view the configuration of a specific VLAN interface. This can help you verify that the VLAN ID, IP address, and other settings are configured correctly. If you're still having trouble, double-check your VLAN configuration, firewall policies, and routing settings. Make sure that the VLAN IDs are configured correctly on all your devices, that your firewall policies are allowing traffic to flow between the VLANs, and that your routing settings are configured to route traffic between the VLANs. Also, make sure that there are not duplicate IP addresses between different VLANs, or it will not work.

Best Practices and Tips

To wrap things up, here are some best practices and tips to keep in mind when configuring VLANs on your FortiGate. First, always plan your VLAN numbering scheme in advance. Use a consistent and logical numbering scheme to make it easier to manage your VLANs in the future. Document your VLAN configuration, including VLAN IDs, interface assignments, and firewall policies. This will make it easier to troubleshoot issues and make changes to your configuration later on. Use descriptive names for your VLAN interfaces. This will help you easily identify the VLANs and understand their purpose. Regularly review your VLAN configuration and firewall policies to ensure they are still meeting your security requirements. As your network evolves, you may need to adjust your VLAN configuration to accommodate new devices, applications, or security threats. Use VLAN trunking to carry traffic for multiple VLANs over a single physical link. This can help you reduce the number of physical cables required to connect your network devices. Secure your VLANs by implementing appropriate firewall policies and access control lists. This will help prevent unauthorized access to your VLANs and protect your network from security threats. Monitor your VLAN traffic to identify any performance issues or security threats. You can use FortiGate's built-in monitoring tools to track VLAN traffic and identify any anomalies. By following these best practices and tips, you can ensure that your VLANs are configured correctly, securely, and efficiently.

Conclusion

Alright, guys, that's pretty much it! Configuring VLANs with 802.1Q on a FortiGate might seem a bit daunting at first, but once you get the hang of it, it's really not that bad. By following the steps and best practices outlined in this guide, you can create a well-organized, secure, and efficient network that meets your specific needs. Remember to plan your VLAN configuration in advance, document your settings, and regularly review your policies to ensure they are still effective. And most importantly, don't be afraid to experiment and learn as you go. With a little practice, you'll be a VLAN pro in no time!
